1.Photosensitive film: 1/4” 1 million pixels

2.Maximum effective pixel: 1280H x 720V

3.Pixel Size: 2.8 x 2.8 µm

4.Image area: 1288H x 728V

5.Output image format

6.Supported resolution and frame rate: HDR 1280x720@30FPS, VGA 640x480@30FPS

7.Camera board assembly technology: SMT (ROSH)

8.Focus: FF

9.Object distance: 30CM-1M

10.Signal-to-noise ratio: 41.0 db

11.Dynamic range: 84.9 db

12.Minimum illumination: TBD

13.Shutter type: Electronic rolling shutter

14.Interface type: USB2.0 High Speed

15.Automatic exposure control AEC: Supported

16.Automatic white balance AEB: Supported

17.Automatic gain control AGC: Supported

18.Adjustable parameters: Brightness Contrast Color saturation Hue Sharpness Gamma White balance Backlight contrast Exposure

19.Lens specifications: Size: 1/4, F/N: F2.2, EFL: 1.64mm, FOV: 120 Degree, IR filter: 650±10nm

20.Power supply and interface: USB BUS POWER 5P-1.25 socket

21.Voltage: DC5V

22.Current: TBD

23.Size: 2.75*2.45cm

24.Storage temperature: -20°C to 70°C

25.Operating temperature: 0°C to 60°C

26.USB cable

27.System support: Win XP/Vista/Win7/Win8 / Linux with UVC (above linux-2.6.26) MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC

28.The total size: 119*55mm
